Blackmagic Design DeckLink SDI 4K
Blackmagic
-
₱22,600.00
-
Out Of Stock
- 0% 3mos BDO, BPI, CITI, HSBC ₱7,533.33/mo.
This item cannot be checked out. For availability, inquiries and interested buyers, kindly chat us on our FB messenger Henry's Cameras PH or send us an email at sales@henryscameraphoto.com.
- SD/HD/3G/6G-SDI Input/Output
- PCIe Interface
- UHD / DCI 4K 4:2:2 by Single-Link 6G-SDI
- 1080p 4:4:4 by Single-Link 3G-SDI
- 10-Bit Processing
- RS-422 Deck Control
- Internal Keying
- Reference Input
- Down/Up/Cross Conversions
- macOS, Windows, and Linux Compatible
Format Support
| Embedded Audio | SDI: 16-Channel |
| Video Resolution | SDI Input (10-Bit 4:4:4/4:2:2) 4096 x 2160 at 23.98/24/25 fps 3840 x 2160 at 23.98/24/25/29.97/30 fps 2048 x 1080 at 23.98/24/25 fps 1920 x 1080p at 23.98/24/25/29.97/30/50/59.94/60 fps 1920 x 1080PsF at 23.98/24/25/29.97/30 fps 1920 x 1080i at 50/59.94/60 fps 1280 x 720 at 50/59.94/60 fps 720 x 576i at 50 fps 720 x 480i at 59.94 fps SDI Output (8-Bit 4:4:4/4:2:2) 4096 x 2160 at 23.98/24/25 fps 3840 x 2160 at 23.98/24/25/29.97/30 fps 2048 x 1080p at 23.98/24/25 fps 1920 x 1080p at 23.98/24/25/29.97/30/50/59.94/60 fps 1920 x 1080PsF at 23.98/24/25/29.97/30 fps 1920 x 1080i at 50/59.94/60 fps 1280 x 720 at 50/59.94/60 fps 720 x 576i at 50 fps 720 x 480i at 59.94 fps |
Inputs / Outputs
| Other I/O | Input 1x BNC (Reference) 1x DE-9/DB-9 (RS-422) |
| Video I/O | Input 1x BNC (6G-SDI) Output 1x BNC (6G-SDI) |
Standards
| Broadcast System Compatibility | NTSC, PAL |
| Video Standard Compliance | SMPTE: 259M/292M/296M/372M/425M/ST-2081 ITU-R: BT.601/BT.656 |
General
| Certifications | C-Tick, CE, FCC |
| Dimension | 3.75" / 9.53 cm |
| Weight | 4.5 oz / 128 g |
| Warranty | 1 Year |
The Decklink SDI 4K Capture & Playback Card from Blackmagic Design features a single multi-rate SDI input and multi-rate SDI output. These multi-rate connections accept single-link SD, HD, 3G, and 6G-SDI signals, providing support for resolutions from SD to Ultra HD 4K (3840 x 2160) and DCI 4K (4096 x 2160). Additionally, the Decklink SDI 4K includes RS-422 deck control, internal keying, and a reference input.
Decklink SDI 4K offers flexible format and system support, letting you work with compressed video formats such as ProRes and DNxHD as well as 10-bit uncompressed video. When working with uncompressed video, all images are pixel-for-pixel identical to the source, without any generational loss. This lets you get sharper keying with green screens, cleaner compositions, superior color correction, and more. Support for common file formats provides ready-to-edit files for use in popular editing, effects, and design software applications. Decklink SDI 4K is compatible with macOS, Windows, and Linux based workstations with downloadable software.
Key Features
- PCIe capture/playback card compatible with macOS, Windows, and Linux based workstations and servers
- 10-bit, 4:2:2 UHD 4K or DCI 4K by single-link 6G-SDI
- 10-bit, 4:4:4 1080p by single-link 6G-SDI
- HD to SD down-conversion
- SD to HD up-conversion
- Hardware cross conversion between 720p and 1080p on playback
- RS-422 deck control
- Internal keying
- Reference input
- Blackburst and tri-sync
- Supports 16 channels of embedded SDI audio in HD, 2K, and 4K resolutions; 8 channels in SD
